특징

Absolute measurement of electrical conductivity of nearly all non-ferrous metals (Ti – Ag)

In the aerospace and automotive industry, monitor the process of heat treatment, the strength

and hardness of aluminum alloy

Test the conductivity when the aluminum have not been oxidized

Measurement the purity of non-ferrous metals

Test the resistivity of conductive materials

Analyze thermal properties of materials.

▪ 사양

디스플레이: 240 x 320 pixels TFT-LCD

측정범위: 1%IACS ~ 105%IACS (0.58 MS/m ~ 61MS/m)

Accuracy: 23%IACS: ±0.25%IACS

                  100%IACS: ±0.5%IACS

Probe 직경: 12.7mm

Operating frequency: 60kHz

Language: English

PC Communication: USB

Reading storage: 1,000 data

Relative humidity: 0 ~ 95%

Operating temperature: 0 ~ 50℃

전원: High performance lithium polymer battery, 100시간

Weight: 245g

L.B.H: 180 x 80 x 35mm
